Compression : GSM-AMR speech encoding, bit rate: 4.75 kbps to 12.2 kbps, MPEG-4 AAC audio encoding, bit rate: 16 kbps to 128 kbps, G.711 audio encoding, bit rate: 64 kbps, μ-Law or A-Law
Dimensions : 170mm x 133 mm
Alarme : Event notification using HTTP, SMTP, or FTP
Sortie audio : yes
Consommation : Power consumption: Max. 5.3 W, Power consumption: Max. 9.9 W (with heater, fan, and IR illuminator), 802.3af compliant Power-over-Ethernet
Nombre d'Images Secondes : H.264: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200, MPEG-4: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200, MJPEG: Up to 30 fps at 1280x720, Up to 15 fps at 1600x1200
Indicateurs : System power and status indicator
Infrarouge : Built-in IR illuminators, Effective up to 20 meters
Mémoire : SD/SDHC card slot
Microphone : External microphone input
clairage minimum : 0 Lux / F1.2 ( IR LED on )
Réseau : 10/100 Mbps Ethernet, RJ-45
Température d'opération : -30 ~ 50 °C (-22 ~ 122 °F ), Humidity: 20 ~ 95%
Mode d'opération : Automatic, manual or scheduled day/night mode
Sortie : BNC
Alimentation d'énergie : 12V DC, 24V AC
Balayage : NTSC/PAL
Sécurité : 802.1X port-based authentication for network protection
Ajustement de la sensibilité : Configurable brightness, contrast, saturation, sharpness, white balance and exposure
Protocoles Supportés : Pv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP and 802.1X
Lecture Vidéo en Transit : Simultaneous multiple streams, H.264 streaming over UDP, TCP, HTTP or HTTPS, H.264/MPEG-4 multicast streaming, MPEG-4 streaming over UDP, TCP, HTTP or HTTPS, MPEG-4 multicast streaming, MJPEG streaming over HTTP or HTTPS, Supports activity adaptive stream
Support vidéo : 23.8° ~ 68.4° (vertical)
Capteur d'image : 1/3.2" CMOS in 1600x1200 Resolution
Connexion/visualisation à distance : Net-i viewer, smart viewer, web viewer, built‐in player for 3GPP / ISMA
