The TALAN incorporates several types of telephone line tests including common tests such as voltage, current, resistance, and capacitance tests, as well as NEW technology such as line NLJD, FDR Frequency Domain Reflectometry, and Digital Demodulation into a single piece of equipment. Additionally, the TALAN utilizes an automatic internal pair switching matrix to automatically perform tests on all pair combinations. The ability to perform several different tests allows the user to compare the results of multiple tests on multiple phone lines, quickly identifying any potentially threatening anomalies.

The TALAN represents a new breakthrough in telephone line testing. There currently is no other product available with the same capabilities.

Features
Combines multiple testing capabilities into a single piece of equipment
Automatic internal pair switching matrix performs tests on all pair combinations
Quickly performs common test functions including:
Multimeter tests (voltage, current, resistance, capacitance)
RF Broadband Detector (up to 8GHz)
Spectrum Analyzer (up to 85MHz)
High Gain Audio Amplifier
Bias Generator ±80 VDC
Audio Oscilloscope with active input (20Hz to 20KHz)


DPA-7000 Advancements
Digital Demodulation to confirm that the telephone line is not passing audio
Frequency Domain Reflectometer (FDR) to check for taps on the line
Line Non-Linear Junction Detector (NLJD) Functionality to detect electronics connected to a line
NLJD Line Trace Probe for tracing wires and locating electronics
Multi-Test Database System provides the ability to perform multiple tests, on all pair combinations, storing data in a database for comparison against other lines and historical comparison


Specifications
Control System

Primary Computer: 32bit RISC processor, 520MHz
Internal Memory: 64MB SDRAM (OS), 64MB Flash
External Memory: Compact Flash to 2GB
Digital I/O

USB Device (A type) supports external keyboard, mouse, and USB Mass Storage devices
Network: 10/100 Ethernet Controller (for future usability)
USB Host (B type, for future usability)
Analog I/O

Headphone Output: 3.5mm Mono connector
Microphone Input: 3.5mm Mono input
User Interface

Hard Keys: 6 Soft Menu Keys, 5 Button Quadrant Navigation & other dedicated keys
Encoder: High-Resolution Optical Encoder
Integrated Touch Screen with Stylus
Test Inputs:
Dual MOD8: Supports 2, 4, 6, & 8 wire Modular Phone Jacks
Banana Type: Standard sleeved sockets: Ring, Tip, and Earth
SMB RF Input: RF/Antenna Connection to 8 GHz Broadband Detector
Expansion Port: Supports communication & measurement for use with future accessories
RF System

Spectrum Analyzer:
Dual Conversion, Super-Heterodyne Receiver
Frequency Range: 10kHz to 85MHz
Sweep Time: 2 Seconds
Step Size: 1kHz
Bandwidth: 18kHz
Sensitivity: -100dBm
Broadband Detector:
RF SMB Input: 100kHz to 8GHz
Balanced Line Test: 100kHz to 600MHz
Sensitivity: -65dBm
Digital Multimeter

Range: Quick Response Auto-Ranging, 500msec Sample Rate
AC/DC Volts: 0 to 250V Maximum
Resistance: 0 to 40 MegOhm
Capacitance: 4nF to 4.2µF
Bias Generator

Optically Isolated, Direct Digital Control: High voltage DAC
Modulation: Fixed voltage, or variable rate Sinewave (10Hz - 300Hz)
Output Ceiling: ± 80V
Audio

Audio Bandwidth: 20Hz - 20KHz
Gain: Up to 80dB total system gain (voice band)
AGC: Digitally Controlled Automatic Gain
Filter: Analog Voice band filter (300Hz to 3kHz)
Power System

External Input: 9 - 15VDC @ 3A
Universal Power Supply: 100-240VAC, 50-60Hz
Removable Battery: Rechargeable Lithium ion, 4-6 hours of run time
Mechanical

Dimensions: 9.5in x 12in x 2in (24.1cm x 30.5cm x 5.0cm)
Unit Weight with Battery: 6 lbs (2.7 kg)
Case Dimensions: 6.25in x 14.9in x 18.5in (15.9cm x 37.8cm x 47.0cm)
Case Weight (Including TALAN and accessories): 11.5 lbs (5.2 kg)
Operating Temperature: 0°C to +50°C
